Commercial Roofing Terminology
Navigating commercial roofing projects requires a clear understanding of industry-specific terms. This glossary is designed to help property managers, building owners, and industry professionals communicate effectively, make informed decisions, and better understand the systems that protect their investments.
Terminology
-
A ballasted roof refers to a type of roofing system where the membrane is held in place by a layer of ballast, typically consisting of gravel, stones, or pavers. The ballast provides weight and stability to keep the roof membrane secure and in position. In a ballasted roof system, the membrane, which can be EPDM, TPO, PVC, or another suitable material, is first laid on the roof deck. Then, a layer of insulation is installed on top of the membrane to provide thermal resistance and energy efficiency. Finally, the ballast layer is spread over the insulation, covering the entire roof surface. The ballast layer serves multiple purposes in a ballasted roof system. It helps to protect the membrane from exposure to ultraviolet (UV) radiation, temperature fluctuations, and physical damage. The weight of the ballast also helps to resist wind uplift forces, providing stability and preventing the membrane from being lifted off the roof deck.
-
Bitumen commercial roofing refers to the use of bitumen-based materials for roofing systems in commercial buildings. Bitumen, also known as asphalt or tar, is commonly used in the construction industry for its waterproofing and durability properties. There are two primary types of bitumen roofing systems used in commercial applications: Built-Up Roofing (BUR) and Modified Bitumen Roofing.
1. Built-Up Roofing (BUR): BUR systems have been used for many years and consist of multiple layers of bitumen and reinforcing fabrics. The layers are alternated and built up to create a durable and waterproof membrane. The number of layers can vary depending on the specific requirements of the project. The top layer of a BUR system is typically embedded with mineral granules or a reflective coating to enhance UV resistance and energy efficiency.
2. Modified Bitumen Roofing: Modified bitumen roofing is a modern variation of BUR systems that incorporates modifiers, such as rubber or plastic, to improve the performance characteristics of the roofing membrane. These modifiers enhance flexibility, elongation, and temperature resistance. Modified bitumen membranes are typically available in either a smooth or granulated surface finish.
-
Commercial coating, also known as roof coating or roof membrane coating, refers to the application of protective coatings on commercial roofs. It involves applying a liquid material to the existing roofing surface to create a seamless and protective layer. Commercial coatings are primarily used to extend the lifespan of roofs, improve energy efficiency, and provide additional protection against leaks, UV radiation, and weathering.
-
Drip edge is an essential component of commercial roofing systems that provides protection and helps channel water away from the roof edges. It is typically made of metal, such as galvanized steel or aluminum, and is installed along the eaves and rakes of the roof.
-
Flashing refers to the materials and components used to create watertight seals and prevent water penetration at vulnerable areas of a commercial roof. Flashing is typically made of metal, such as aluminum, copper, or galvanized steel, and is installed at various points where the roof intersects with other structures or objects, such as walls, chimneys, vents, skylights, or equipment penetrations.
-
A flat roof is a type of roof that has a very low slope or pitch, often appearing as a horizontal or nearly horizontal surface. While it is called a "flat" roof, it is not entirely flat but has a slight pitch to allow for proper drainage of rainwater. A flat roof has a slopf 3 or less. It's important to note that despite the name "flat roof," these roofs should still have a slight slope for proper water drainage. Without proper maintenance and regular inspection, flat roofs can be prone to water pooling, which can lead to leaks and other issues. Professional installation and regular maintenance are crucial to ensure the longevity and performance of a flat roof.
-
A fully adhered roof refers to a roofing system where all components, including the insulation and membrane, are securely bonded or adhered to the roof deck or substrate. This type of roofing installation provides a watertight and durable solution. The main advantage of a fully adhered roof is its excellent resistance to wind uplift. Since all components are securely bonded, the roofing system can withstand strong winds and severe weather conditions. This makes fully adhered roofs suitable for buildings located in areas prone to hurricanes or high wind zones. Additionally, a fully adhered roof provides superior waterproofing because the membrane is directly adhered to the substrate. This minimizes the risk of water infiltration and leaks. The adhesion also helps to distribute the weight of the roofing system evenly, reducing the stress on individual components and extending the roof's lifespan.
-
A mechanically attached roof refers to a roofing system where the components, such as insulation and membrane, are secured to the roof deck using mechanical fasteners rather than adhesives. This method provides a reliable and efficient way to install a roof. In a mechanically attached roof system, insulation boards or panels are placed on the roof deck, and they are then fastened to the deck using screws, nails, or other types of mechanical fasteners. Once the insulation is in place, a membrane, such as EPDM, TPO, or PVC, is laid over the insulation and mechanically attached to the roof deck using fasteners, such as screws or plates.
-
When it comes to roofing, the terms "slope" and "pitch" are often used interchangeably to describe the angle or steepness of a roof. However, technically speaking, there is a slight difference between the two. In practical terms, the slope or pitch of a roof determines its aesthetic appearance, water shedding capabilities, and the type of roofing materials suitable for installation. Steeper roofs with a higher slope or pitch are more effective at shedding water and are often seen in areas with heavy rainfall or snowfall. Flatter roofs with a lower slope or pitch are typically found in drier climates. Ultimately, whether you use the term "slope" or "pitch" to describe a roof, they both refer to the angle of incline and play a crucial role in roof design and functionality
-
Commercial reroofing refers to the process of replacing an existing roof on a commercial building with a new roofing system. It involves removing the old roofing materials and installing a new roof to improve the functionality, performance, and appearance of the building's roof. Commercial reroofing is typically undertaken when the existing roof has reached the end of its lifespan, suffered extensive damage, or when there is a need to upgrade the roofing system for various reasons.
-
The roof deck refers to the structural base or substrate of a roof. It is the foundation upon which the roofing materials are installed. The roof deck provides support and stability to the roof system and helps distribute the weight of the roofing materials and any additional loads.
-
Vents in commercial roofing play a crucial role in maintaining a well-ventilated and healthy roofing system. They help regulate the air circulation and moisture levels within the building, preventing excessive heat buildup, condensation, and potential damage to the roof and underlying structures.
Materials
-
EPDM stands for Ethylene Propylene Diene Monomer, which is a type of synthetic rubber commonly used in various applications, including roofing. EPDM rubber is known for its excellent weather resistance, durability, and flexibility. In the roofing industry, EPDM rubber is used as a roofing membrane to provide a waterproof and protective layer.
-
Galvanized steel refers to steel that has been coated with a layer of zinc to provide protection against corrosion. The process of galvanization involves immersing the steel into a bath of molten zinc or applying a zinc coating through electroplating.
The zinc coating on galvanized steel serves as a sacrificial layer, meaning it corrodes preferentially to protect the underlying steel from rust and other forms of corrosion. This makes galvanized steel highly resistant to atmospheric, water, and chemical corrosion, making it suitable for a wide range of applications, including commercial roofing, construction, automotive, and industrial uses.
-
A PVC membrane, also known as PVC roofing or PVC single-ply roofing membrane, is a type of synthetic roofing material commonly used in commercial and industrial buildings. PVC stands for polyvinyl chloride, which is a thermoplastic polymer. PVC membranes are designed to provide durability, flexibility, and weather resistance.
-
Metal commercial roofing refers to the use of metal materials for roofing systems in commercial buildings. Metal roofs are popular for their durability, longevity, and aesthetic appeal. They are commonly found in a variety of commercial structures, including office buildings, warehouses, retail stores, and industrial facilities.
-
TPO stands for Thermoplastic Olefin, which is a type of single-ply roofing membrane used in commercial and industrial roofing applications. TPO roofing is known for its durability, energy efficiency, and ease of installation.
Roof Issues
-
Ice dams can pose significant challenges for commercial roofing systems during cold weather conditions. An ice dam forms when snow on the roof melts, flows down the slope, and refreezes at the roof's colder edge or overhang. This ice buildup can lead to water infiltration beneath the roofing materials, causing leaks and potential damage to the roof and building interior.
-
Thermal stress can impact commercial roofing systems, particularly those that are exposed to significant temperature fluctuations. Thermal stress occurs when there are rapid or extreme temperature changes that cause the roofing materials to expand or contract. Over time, this repeated expansion and contraction can lead to various issues, including cracks, leaks, and premature deterioration of the roof.
-
Water infiltration is a common issue in commercial roofing systems that can lead to significant damage if not addressed promptly. Water infiltration occurs when water penetrates through the roof surface, roofing materials, or roof components and enters the building. It can result from various factors, including poor installation, aging or damaged roofing materials, improper sealing, clogged drains or gutters, and extreme weather conditions.
-
Wind uplift is a significant concern for commercial roofing systems, particularly in areas prone to strong winds or severe weather conditions. Wind uplift occurs when the force of the wind creates a pressure difference between the exterior and interior surfaces of the roof, causing upward forces that can potentially lift or displace the roofing materials. Proper design, installation, and maintenance are crucial to mitigating the risk of wind uplift in commercial roofing.
